Marca

• Asus

Modelo

• Prime B520m-k
• 90mb1500-m0eay0)

Plataforma

• - M-atx (22.6 Cm X 22.1 Cm)

Chipset

• - Amd® A520

Cpu

• Soportados- Admite Procesadores Con Socket Amd
• Am4

Memoria

• - 2 X Dimm, Max. 64gb,
• Ddr4 4600(o.c)/4400(o.c)/4000(o.c.)/3866(o.c.)/3733(o.c.)/3600(o.c.)/3466(o.c.)/3333(o.c.)/3200/3000/2800/2666/2400/2133 Mhz Un-buffered Memory
• - Dual Channel Memory Architecture
• - Ecc Memory (ecc Mode)

Slots Expansión

• 3rd Gen Amd Ryzen With Radeon Graphics Processors
• - 1 X Pcie 3.0 X16 (x16 Mode)
• Amd B550 Chipset
• - 2 X Pcie 3.0 X1

Gráficos

• - 1 X D-sub
• - 1 X Hdmi 2.1(4k@60hz)

Internos- 1 X Cpu Fan

• - 1 X Chassis Fan
• - 1 X Usb 3.2 Gen 1
• - 2 X Usb 2.0
• - 1 X M.2 Socket 3 With M Key, Type 2242/2260/2280
• - 1 X Spi Tpm Header
• - 4 X Sata 6gb/s
• - 1 X S/pdif Out Header
• - 1 X 24-pin Eatx Power
• - 1 X 8-pin Eatx 12v Power
• - 1 X Front Panel Audio (aafp)
• - 1 X Clear Cmos Jumper
• - 1 X System Panel
• - 1 X Com Port Header
• - 1 X Speaker

Externos- 1 X Ps/2 Keyboard/mouse Combo Port(s)

• - 1 X D-sub
• - 1 X Hdmi
• - 1 X Lan (rj45) Port(s)
• - 4 X Usb 3.2 Gen 1 (blue) Type-a
• - 2 X Usb 2.0
• - 3 X Audio Jack(s)

Almacenamiento

• - 1 X M.2
• - 4 X Sata 6gb/s
• - Soporta
• Raid 0, 1, 10

Usb

• - 4 X Usb 3.2 Gen 1 (4 X Type-a)
• - 2 X Usb 2.0 (2 X Type-a)
• - 2 X Usb 3.2 Gen 1 (2 X Type-a)
• - 4 X Usb 2.0 (4 X Type-a)

Red

• - Realtek Rtl8111h 1gb Ethernet
• - Asus Languard

Audio

• - Realtek Alc887 7.1 Surround Sound High Definition Audio Codec

Garantía

• Tres Años
