Marca

• Godex

Modelo

• G530

Impresión

• - Tecnología De Impresión: Thermal Transfer / Direct Thermal
• - Resolución: 300 Dpi (12 Dots/mm)
• - Velocidad De Impresión: 4ips (102 Mm/s)
• - Anchura De Impresión: 4.16- (105.7 Mm)
• - Longitud De Impresión: Min. 0.16- (4 Mm)**; Max. 30- (762 Mm)

Papel

• - Papel: Types: Continuous Form, Gap Labels, Black Mark Sensing, And Punched Hole; Label Length Set By Auto Sensing Or Programming
• - Cinta: Types: Wax, Wax/resin, Resin

Conexiones

• - Usb
• - Rs-232
• - Ethernet

Otras Caracteristicas

• - Procesador: 32 Bit Risc Cpu
• - Memoria: 8mb Flash (4mb For User Storage) / 16mb Sdram
• - Tipo De Sensor: Adjustable Reflective Sensor. Fixed Transmissive Sensor, Central Aligned
• - Emulaciones: Ezpl, Gepl, Gzpl Auto Switch
• - Software: Label Design Software: Qlabel-iv (for Ezpl Only), Golabel (for Ezpl Only)
• Driver: Windows 2000, Xp, Vista, 7,8, Windows Server 2003 & 2008
• Dll: Windows 2000, Xp And Vista
• - Fuentes Residentes: Bitmap Fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16x26 And Ocr A & B
• Bitmap Fonts 90°, 180°, 270° Rotatable, Single Characters 90°, 180°, 270° Rotatable
• Bitmap Fonts 8 Times Expandable In Horizontal And Vertical Directions
• Scalable Fonts 90°, 180°, 270° Rotatable
• - Fuentes Descargadas: Bitmap Fonts 90°, 180°, 270° Rotatable, Single Characters 90°, 180°, 270° Rotatable
• Asian Fonts 90°, 180°, 270° Rotatable And 8 Times Expandable In Horizontal And Vertical Directions
• Scalable Fonts 90°, 180°, 270° Rotatable
• - Códigos De Barras: 1-d Bar Codes:
• Code 39, Code 93, Ean 8/13 (add On 2 & 5), Upc A/e (add On 2 & 5), I 2 Of 5 & I 2 Of 5 With Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), Ean 128, Rps 128, Ucc 128, Ucc/ean-128 K-mart, Random Weight, Post Net, Itf 14, China Postal Code, Hibc, Msi, Plessey, Telepen, Fim, Gs1 Databar, German Post Code, Planet 11 & 13 Digit, Japanese Postnet, I2 Of 5 With Human Readable Check Digit, Standard 2 Of 5, Industrial 2 Of 5 , Logmars, Code 11, Code 49, Cadablock
• 2-d Bar Codes:
• Pdf417, Datamatrix Code, Maxicode, Qr Code, Micro Pdf417, Micro Qr Code And Aztec Code
• - Páginas De Código: Codepage 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
• Windows 1250, 1251, 1252, 1253, 1254, 1255, 1257
• Unicode (utf8, Utf16)
• - Gráficos: Resident Graphic File Types Are Bmp And Pcx, Other Graphic Formats Are Downloadable From The Software
• - Panel De Control: Two Bi-color Status-leds: Ready, Status
• Control Key: Feed
• - Alimentación: Auto Switching 100-240vac, 50-60hz
• - Entorno:
• Temperatura De Operación: 41°f To 104°f (5°c To 40°c)
• Temperatura De Almacenamiento: -4°f To 122°f (-20°c To 50°c)
• Humedad:
• Operación: 30-85%, Non-condensing.
• Almacenamiento: 10-90%, Non-condensing.
• - Aprobaciones: Ce(emc), Fcc Class A, Cb, Cul, Ccc
• - Dimensiones:
• Largo: 11.2- (285 Mm)
• Alto: 6.8- (171 Mm)
• Ancho: 8.9- (226 Mm)
• - Peso: 6 Lbs (2.72kg), Excluding Consumables

Garantía

• Tres Años
