Cpu

Intel® Socket Lga1700 For 13th Gen Intel® Core- Processors & 12th Gen Intel® Core-, Pentium® Gold And Celeron® Processors*

• Supports Intel® Turbo Boost Technology 2.0 And Intel® Turbo Boost Max Technology 3.0**
• *refer To Www.asus.com For Cpu Support List.
• ** Intel® Turbo Boost Max Technology 3.0 Support Depends On The Cpu Types.

Chipset

Intel® B760 Chipset

Memory

4 X Dimm, Max. 128gb, Ddr4 5333(oc)/ 5066(oc)/ 5000(oc)/ 4800(oc)/ 4600(oc)/ 4400(oc)/ 4266(oc)/ 4000(oc)/ 3733(oc)/ 3600(oc)/ 3466(oc)/3400(oc)/3333(oc)/3200/3000/2933/2800/2666/2400/2133 Non-ecc, Un-buffered Memory*

• Dual Channel Memory Architecture
• Supports Intel® Extreme Memory Profile (xmp)
• Optimem Ii
• * Supported Memory Types, Data Rate(speed), And Number Of Dram Modules Vary Depending On The Cpu And Memory Configuration, For More Information Refer To Www.asus.com For Memory Support List.

Graphics

1 X Displayport**

• 2 X Hdmi® Ports***
• * Graphics Specifications May Vary Between Cpu Types. Please Refer To Www.intel.com For Any Updates.
• ** Supports Max. 4k@60hz As Specified In Displayport 1.4.
• *** Supports 4k@60hz As Specified In Hdmi® 2.1.

Expansion Slots

Intel® 13th & 12th Gen Processors

• 1 X Pcie 4.0 X16 Slot
• Intel® B760 Chipset
• 1 X Pcie 4.0 X16 Slot (supports X4 Mode)
• 1 X Pcie 4.0 X16 Slot (supports X1 Mode)
• Note: To Ensure Compatibility Of The Device Installed, Please Refer To Https://www.asus.com/support/ For The List Of Supported Peripherals.

Storage

Total Supports 2 X M.2 Slots And 4x Sata 6gb/s Ports*

• Intel® 13th & 12th Gen Processors
• M.2_1 Slot (key M), Type 2242/2260/2280 (supports Pcie 4.0 X4 Mode)
• Intel® B760 Chipset
• M.2_2 Slot (key M), Type 2242/2260/2280 (supports Pcie 4.0 X4 Mode)
• 4 X Sata 6gb/s Ports
• * Intel® Rapid Storage Technology Supports Sata Raid 0/1/5/10.

Ethernet

1 X Realtek 2.5gb Ethernet

Usb

Rear Usb (total 6 Ports)

• 2 X Usb 3.2 Gen 2 Ports (2 X Type-a )
• 4 X Usb 2.0 Ports (4 X Type-a)
• Front Usb (total 10 Ports)
• 2 X Usb 3.2 Gen 1 Headers Support 4 Additional Usb 3.2 Gen 1 Ports
• 1 X Usb 3.2 Gen 1 Connector (supports Usb Type-c®)
• 2 X Usb 2.0 Headers Support 4 Additional Usb 2.0 Ports
• 1 X Usb 2.0 Header Supports 1 Additional Usb 2.0 Port

Audio

Realtek 7.1 Surround Sound High Definition Audio Codec*

• - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
• - Supports Up To 24-bit/192 Khz Playback
• Audio Features
• - Audio Shielding
• - Premium Audio Capacitors
• - Dedicated Audio Pcb Layers
• * A Chassis With An Hd Audio Module In The Front Panel Is Required To Support 7.1 Surround Sound Audio Output.

Back Panel I/o Ports

2 X Usb 3.2 Gen 2 Ports (2 X Type-a )

• 4 X Usb 2.0 Ports (4 X Type-a)
• 1 X Displayport
• 2 X Hdmi® Ports
• 1 X Realtek 2.5gb Ethernet Port
• 3 X Audio Jacks
• 1 X Ps/2 Keyboard/mouse Combo Port

Internal I/o Connectors

Fan And Cooling Related

• 1 X 4-pin Cpu Fan Header
• 1 X 4-pin Cpu Opt Fan Header
• 2 X 4-pin Chassis Fan Headers
• Power Related
• 1 X 24-pin Main Power Connector
• 1 X 8-pin +12v Power Connector
• Storage Related
• 2 X M.2 Slots (key M)
• 4 X Sata 6gb/s Ports
• Usb
• 2 X Usb 3.2 Gen 1 Headers Support 4 Additional Usb 3.2 Gen 1 Ports
• 1 X Usb 3.2 Gen 1 Connector (supports Usb Type-c®)
• 2 X Usb 2.0 Headers Support 4 Additional Usb 2.0 Ports
• 1 X Usb 2.0 Header Supports 1 Additional Usb 2.0 Port
• Miscellaneous
• 3 X Addressable Gen 2 Headers
• 1 X Aura Rgb Header
• 1 X Clear Cmos Header
• 1 X Com Port Header
• 1 X Front Panel Audio Header (aafp)
• 1 X Lpt Header
• 1 X S/pdif Out Header
• 1 X Spi Tpm Header (14-1pin)
• 1 X 20-3 Pin System Panel Header With Chassis Intrude Function

Bios

128 Mb Flash Rom, Uefi Ami Bios

Manageability

Wol By Pme, Pxe

Form Factor

Matx Form Factor

• 9.6 Inch X 9.6 Inch ( 24.4 Cm X 24.4 Cm )

Garantía

• Tres Años
