Cpu

Amd Socket Am5 For Amd Ryzen- 7000 Series Desktop Processors*

• * Refer To Www.asus.com For Cpu Support List.

Chipset

Amd X670

Memoria

4 X Dimm, Max. 128gb, Ddr5 6400+(oc)/ 6200(oc)/ 6000(oc)/ 5800(oc)/ 5600(oc)/ 5400(oc)/ 5200/ 5000/ 4800 Ecc & Non-ecc, Un-buffered Memory*

• Dual Channel Memory Architecture
• Supports Amd Extended Profiles For Overclocking (expo-)
• Optimem Ii
• * Supported Memory Types, Data Rate(speed), And Number Of Dram Module Vary Depending On The Cpu And Memory Configuration, For More Information Refer To Www.asus.com For Memory Support List.
• ** Non-ecc, Un-buffered Ddr5 Memroy Supports On-die Ecc Function.

Gráficos

1 X Displayport**

• 1 X Hdmi® Port***
• * Graphics Specifications May Vary Between Cpu Types.
• ** Supports Max. 8k@60hz As Specified In Displayport 1.4.
• *** Supports 4k@60hz As Specified In Hdmi 2.1.

Ranuras De Expansión

Amd Ryzen- 7000 Series Desktop Processors*

• -1 X Pcie 5.0 X16 Slot
• Amd X670 Chipset
• -1 X Pcie 4.0 X16 Slot (supports X4 Mode)
• -1 X Pcie 4.0 X4 Slots
• * Please Check Pcie Bifurcation Table At Https://www.asus.com/support/faq/1037507/.

Almacenamiento

Total Supports 4 X M.2 Slots And 4 X Sata 6gb/s Ports*

• Amd Ryzen- 7000 Series Desktop Processors
• M.2_1 Slot (key M), Type 2242/2260/2280 (supports Pcie 5.0 X4 Mode)
• M.2_3 Slot (key M), Type 2242/2260/2280 (supports Pcie 4.0 X4 Mode)
• Amd X670 Chipset
• M.2_2 Slot (key M), Type 2242/2260/2280/22110 (supports Pcie 3.0 X4 & Sata Modes)**
• M.2_4 Slot (key M), Type 2242/2260/2280 (supports Pcie 4.0 X4 Mode)
• 4 X Sata 6gb/s Ports
• *amd Raid Xpert Technology Supports Both Nvme Raid 0/1/10 And Sata Raid 0/1/10.
• ** M.2_2 Slot Shares Bandwidth With Sata6g_1&2. When M.2_2 Runs At Pcie X4 Mode, Sata6g_1&2 Will Be Disabled.

Ethernet

1 X Realtek 2.5gb Ethernet

• Tuf Languard

Usb

Rear Usb (total 10 Ports)

• 1 X Usb 3.2 Gen 2x2 Port (1 X Usb Type-c®)
• 4 X Usb 3.2 Gen 2 Ports (3 X Type-a + 1 X Usb Type-c®)
• 5 X Usb 3.2 Gen 1 Ports (5 X Type-a)
• Front Usb (total 9 Ports)
• 1 X Usb 3.2 Gen 2 Connector (supports Usb Type-c®)
• 1 X Usb 3.2 Gen 1 Header Supports Additional 2 Usb 3.2 Gen 1 Ports
• 3 X Usb 2.0 Headers Support Additional 6 Usb 2.0 Ports

Audio

Realtek S1220a 7.1 Surround Sound High Definition Audio Codec*

• - Impedance Sense For Front And Rear Headphone Outputs
• - Internal Audio Amplifier To Enhance The Highest Quality Sound For Headphone And Speakers
• - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
• - High Quality 120 Db Snr Stereo Playback Output And 113 Db Snr Recording Input (line-in)
• - Supports Up To 32-bit/192 Khz Playback*
• Audio Features
• - Audio Shielding
• - Premium Audio Capacitors
• - Dedicated Audio Pcb Layers
• - Audio Cover
• - Unique De-pop Circuit
• * Due To Limitations In Hda Bandwidth, 32-bit/192 Khz Is Not Supported For 7.1 Surround Sound Audio.

Puertos De E/s Del Panel Posterior

1 X Usb 3.2 Gen 2x2 Port (1 X Usb Type-c®)

• 4 X Usb 3.2 Gen 2 Ports (3 X Type-a, 1 X Usb Type-c®)
• 5 X Usb 3.2 Gen 1 Ports (5 X Type-a)
• 1 X Displayport
• 1 X Hdmi® Port
• 1 X Wi-fi Module
• 1 X Realtek 2.5gb Ethernet Port
• 5 X Audio Jacks
• 1 X Bios Flashback- Button

Conectores De E/s Internos

Fan And Cooling Related

• 1 X 4-pin Cpu Fan Header
• 1 X 4-pin Cpu Opt Fan Header
• 1 X 4-pin Aio Pump Header
• 4 X 4-pin Chassis Fan Headers
• 1 X W_pump+ Header
• Power Related
• 1 X 24-pin Main Power Connector
• 2 X 8-pin +12v Power Connectors
• Storage Related
• 4 X M.2 Slots (key M)
• 4 X Sata 6gb/s Ports
• Usb
• 1 X Usb 3.2 Gen 2 Connector (supports Usb Type-c®)
• 1 X Usb 3.2 Gen 1 Header Supports Additional 2 Usb 3.2 Gen 1 Ports
• 3 X Usb 2.0 Headers Support Additional 6 Usb 2.0 Ports
• Miscellaneous
• 3 X Addressable Gen 2 Headers
• 1 X Aura Rgb Header
• 1 X Clear Cmos Header
• 1 X Com Port Header
• 1 X Front Panel Audio Header (aafp)
• 1 X 20-3 Pin System Panel Header With Chassis Intrude Function
• 1 X Thermal Sensor Header
• 1 X Thunderbolt- Header

Bios

256 Mb Flash Rom, Uefi Ami Bios

• Manejabilidad
• Wol By Pme, Pxe

Factor De Forma

Atx Form Factor

• 12 Inch X 9.6 Inch ( 30.5 Cm X 24.4 Cm )

Garantía

• Tres Años
