Descripción Del Producto

• Cpu 1.support For Am3 Processors: Amd Phenom- Ii Processor / Amd
• Athlon- Ii Processor
• Hyper Transport Bus 1.2000 Mt / S
• Chipset 1.nvidia® Geforce 7025 / Nforce 630a Chipset
• Memory 1.2 X 1.5v Ddr3 Dimm Sockets Supporting Up To 8gb Of System
• Memory (note 1)
• 2.dual Channel Memory Architecture
• 3.support For Ddr3 1666+ / 1333 / 1066 / 800 Mhz Memory Modules
• Onboard Graphics Integrated In The Chipset:
• 1.1 X D-sub Port
• Audio 1.realtek Alc888b Codec
• 2.high Definition Audio
• 3.2 / 4 / 5.1 / 7.1-channel (note 2)
• 4.support For Spdif In
• 5.support For Spdif Out
• 6.support For Cd In

Lan

• 1.onboard Realtek Rtl8211cl (10 / 100 / 1000mbit)

Expansión Slots

• 1.1 X Pci Express X16 Slot, Running At X16
• 2.1 X Pci Express X1 Slot
• 3.2 X Pci Slots

Storage Interface

• Nvidia® Geforce 7025 / Nforce 630a Chipset
• 1.1 X Ide Connector Supporting Ata-133 / 100 / 66 / 33 And Up To 2 Ide Devices
• 2.4x Sata 3gb / S Connectors Supporting Up To 4 Sata 3gb / S Devices
• 3.support For Raid 0, Raid 1, Raid 5, Raid 10 And Jbod Ite It8720 Chip:

Floppy Disk Drive Connector

• Supporting Up To 1 Floppy Disk Drive

Usb Chipset:

• 1.up To 8 Usb 2.0 / 1.1 Ports (4 On The Back Panel, 4 Via The Usb Brackets Connected To The Internal Usb Headers)

Internal I / O Connectors

• 1.1 X 24-pin Atx Power Connector
• 2.1 X 4-pin Atx 12v Power Connector
• 3.1 X Floppy Connector
• 4.1 X Ide Connectors
• 5.4 X Sata 3gb / S Connectors
• 6.1 X Cpu Fan Header
• 7.1 X System Fan Header
• 8.1 X Front Panel Header
• 9.1 X Front Panel Audio Header
• 10.1 X Cd In Connector
• 11.1 X Spdif In / Out Header
• 12.2 X Usb 2.0 / 1.1 Headers
• 13.1 X Clearing Cmos Jumper

Back Panel Connectors

• 1.1 X Ps / 2 Keyboard Port
• 2.1 X Ps / 2 Mouse Port
• 3.1 X Parallel Port
• 4.1 X Serial Port
• 5.1 X D-sub Port
• 6.4 X Usb 2.0 / 1.1 Ports
• 7.1 X Rj-45 Port
• 8.3 X Audio Jacks (line In / Line Out / Mic In)

I / O Controller

• 1.ite It8720 Chip

H / W Monitoring

• 1.system Voltage Detection
• 2.cpu / System Temperature Detection
• 3.cpu / System Fan Speed Detection
• 4.cpu / System Warning Temperature
• 5.cpu / System Fan Failure Warning
• 6.cpu Fan Speed Control (note 3)

Bios

• 1.2 X 8 Mbit Flash
• 2.use Of Licensed Award Bios
• 3.support For Dualbios-
• 4.pnp 1.0a, Dmi 2.0, Sm Bios 2.4, Acpi 1.0b

Unique Features

• 1.supports @bios
• 2.supports Q-flash
• 3.support For Xpress Bios Rescue
• 4.supports Download Center
• 5.supports Xpress Install
• 6.supports Xpress Recovery2
• 7.supports Easytune(note 4)
• 8.support For Auto Green
• 9.support For On / Off Charge

Garantía

• 2 Años
