Detalles Técnicos

• Procesador 1.l3 Cache Varies With Cpu
• 2.support For Intel® Core- I7 Processors / Intel® Core- I5 Processors / Intel®
• Core- I3 Processors / Intel® Pentium® Processors / Intel® Celeron®
• Processors In The Lga1155 Package (go To Gigabyte-s Website For The Latest
• Cpu Support List.)

Chipset

• 1.intel® P67 Express

Memoria

• 1.4 X 1.5v Ddr3 Dimm Sockets Supporting Up To 32gb Of System Memory
• 2.arquitectura De Memoria Dual Channel
• 3.support For Ddr3 2133 / 1866 / 1600 / 1333 / 1066 Mhz Memory Modules
• 4.support For Non-ecc Memory Modules
• 5.support For Extreme Memory Profile (xmp) Memory Modules
• 6.* Due To Windows 32-bit Operating System Limitation, When More Than 4gb Of Physical Memory Is Installed, The Actual Memory Size Displayed Will Be Less Than 4 Gb.
• 7.go To Gigabyte-s Website For The Latest Supported Memory Speeds And Memory Modules.

Audio

• 1.high Definition Audio
• 2.realtek Alc889 Codec
• 3.support For Dolby® Home Theater
• 4.2 / 4 / 5.1 / 7.1-channel
• 5.support For Spdif Out

Lan

• 1.1 X Rtl8111e Chip (10 / 100 / 1000 Mbit)

Zócalos De Expansión

• 1.1 X Pci Express X16 Slot, Running At X16 (pciex16)
• 2.1 X Pci Express X16 Slot, Running At X8 (pciex8)
• 3.3 X Pci Express X1 Slot (all Pci Express Slots Conform To Pci Express 2.0
• Standard.)
• 4.2 X Pci

Multi Graphics Technology

• 1.support For Ati Crossfirex- / Nvidia Sli
• Technology

Storage Interface Chipset:

• 1.support For Sata Raid 0, Raid 1, Raid 5, And Raid 10
• 2.2 X Sata 6gb / S Connectors (sata3_0, Sata3_1) Supporting Up To 2 Sata 6gb / S Devices
• 3.4 X Sata 3gb / S Connectors (sata2_2~sata2_5) Supporting Up To 4 Sata 3gb / S Devicesmarvell 88se9128 Chip:
• 1.2 X Esata 6gb / S Connectors On The Back Panel Supporting Up To 2 Sata 6gb / S Devices
• 2.support For Sata Raid 0 And Raid 1

Usb Chipset:

• 1.up To 14 Usb 2.0 / 1.1 Ports (8 On The Back Panel, 6 Via The Usb Brackets Connected To The Internal Usb Headers)
• 2 X Renesas D720200 Chips:
• 1.up To 4 Usb 3.0 / 2.0 Ports (2 On The Back Panel, 2 Via The Usb Brackets Connected To The Internal Usb Headers)

Conectores Internos E / S

• 1.2 X Cabeceras Para Ventilador Del Sistema
• 2.4 X Sata 3gb / S
• 3.3 X Usb 2.0 / 1.1
• 4.1 X Serial Port
• 5.1 X Clearing Cmos Jumper
• 6.1 X Cpu Fan Header
• 7.1 X Front Panel Header
• 8.2 X Sata 6gb / S
• 9.1 X 24-pin Atx Main Power Connector
• 10.1 X Front Panel Audio Header
• 11.1 X Usb 3.0 / 2.0 Header
• 12.1 X Spdif Out
• 13.1 X Conector Para Ventilador De La Fuente De Alimentación
• 14.1 X Conector De Alimentación Atx 12v 8-pin

Panel E / S Trasero

• 1.8 X Usb 2.0 / 1.1
• 2.2 X Usb 3.0 / 2.0
• 3.1 X Ps / 2 Keyboard / Mouse Port
• 4.2 X Esata 6gb / S Ports
• 5.1 X Rj45 Lan
• 6.6 X Jacks De Audio (line In / Line Out / Mic In / Surround (traseros) / Central / Subwoofer / Laterales)
• 7.1 X Salida Coaxial S / P-dif
• 8.1 X Salida Óptica S / P-dif

I / O Controller

• 1.ite It8728

Monitorización Hardware

• 1.cpu / System Fan Speed Control
• 2.detección De La Temperatura De Cpu / Sistema
• 3.detección Del Voltaje Del Sistema
• 4.aviso De Sobrecalentamiento De La Cpu
• 5.detección De La Velocidad Del Ventilador De Cpu / Sistema / Alimentación
• 6.aviso De Fallo En El Ventilador De Cpu / Sistema / Alimentación

Bios

• 1.soporta Dualbios-
• 2.pnp 1.0a, Dmi 2.0, Sm Bios 2.4, Acpi 1.0b
• 3.use Of Licensed Award Bios
• 4.2 X 32 Mbit Flash

Otras Características

• 1.support For Q-share
• 2.support For Dynamic Energy Saver- 2
• 3.support For Smart 6-
• 4.auto Green
• 5.extreme Hard Drive
• 6.support For On / Off Charge
• 7.support For Cloud Oc
• 8.support For Easytune
• 9.q-flash-
• 10.download Center
• 11.xpress- Install
• 12.xpress- Recovery 2
• 13.@bios-
• 14.soporta Xpress Bios Rescue

Software Incluido

• 1.norton Internet Security (versión Oem)

Sistema Operativo

• 1.microsoft® Windows® 7 / Vista / Xp

Formato

• 1.atx, 305mm X 244mm

Garantía

• 2 Años
