Procesador

• -supports 2nd Generation Intel® Core- Processors In The
• Lga1155 Package

Chipset

• -intel® H67 Express

Memoria

• -4 X 1.5v Ddr3 Dimm Sockets Supporting Up To 16gb Of System Memory
• -arquitectura De Memoria Dual Channel
• -ddr3 1333 / 1066 / 800 Mhz
• -support For Non-ecc Memory Modules
• -support For Extreme Memory Profile (xmp) Memory Modules
• -* Due To Windows 32-bit Operating System Limitation, When More Than 4gb Of Physical Memory Is Installed, The Actual Memory Size Displayed Will Be Less Than 4 Gb.

Audio

• -2 / 4 / 5.1 / 7.1-channel
• -high Definition Audio
• -realtek Alc892 Codec
• -support For Spdif Out

Lan

• -1 X Rtl8111e Chip (10 / 100 / 1000 Mbit)

Zócalos De Expansión

• -1 X Pci Express X16 Slot, Running At X16 (pciex16)
• -1 X Pci Express X16 Slot, Running At X4 (pciex4)
• -2 X Pci
• -3 X Pci Express X1 Slot (all Pci Express Slots Conform To Pci Express 2.0 Standard.)

Multi Graphics Technology

• -support For Ati Crossfirex- Technology

Storage Interface

• -chipset:
• ?2 X Sata 6gb / S Connectors (sata3_0, Sata3_1) Supporting Up To 2 Sata 6gb / S Devices
• ?4 X Sata 3gb / S Connectors (sata2_2~sata2_5) Supporting Up To 4 Sata 3gb / S Devices
• ?support For Sata Raid 0, Raid 1, Raid 5, And Raid 10
• * When A Raid Set Is Built Across The Sata 6gb / S And Sata 3gb / S Channels, The System Performance Of The Raid Set May Vary Depending On The Devices Being Connected.

Usb

• -chipset:
• ?up To 12 Usb 2.0 / 1.1 Ports (8 On The Back Panel, 4 Via The Usb Brackets
• Connected To The Internal Usb Headers)
• -renesas D720200 Chip:
• ?up To 2 Usb 3.0 / 2.0 Ports On The Back Panel.

Conectores Internos E / S

• -1 X 24-pin Atx Main Power Connector
• -1 X Conector De Alimentación Atx 12v 8-pin
• -1 X Clearing Cmos Jumper
• -1 X Cpu Fan Header
• -1 X Front Panel Audio Header
• -1 X Front Panel Header
• -1 X Conector Para Ventilador De La Fuente De Alimentación
• -1 X Serial Port
• -1 X Spdif Out
• -2 X Sata 6gb / S
• -2 X Cabeceras Para Ventilador Del Sistema
• -2 X Usb 2.0 / 1.1
• -4 X Sata 3gb / S

Panel E / S Trasero

• -1 X Ps / 2 Keyboard / Mouse Port
• -1 X Rj45 Lan
• -1 X Salida Coaxial S / P-dif
• -1 X Salida Óptica S / P-dif
• -2 X Usb 3.0 / 2.0
• -6 X Jacks De Audio (line In / Line Out / Mic In / Surround (traseros) / Central / Subwoofer / Laterales)
• -8 X Usb 2.0 / 1.1

I / O Controller

• -ite It8728

Monitorización Hardware

• -aviso De Sobrecalentamiento De La Cpu
• -cpu / System Fan Speed Control
• *whether The Cpu / System Fan Speed Control Function Is Supported Will Depend On The Cpu / System Cooler You Install.
• -detección De La Temperatura De Cpu / Sistema
• -aviso De Fallo En El Ventilador De Cpu / Sistema / Alimentación
• -detección De La Velocidad Del Ventilador De Cpu / Sistema / Alimentación
• -detección Del Voltaje Del Sistema

Bios

• -2 X 32 Mbit Flash
• -pnp 1.0a, Dmi 2.0, Sm Bios 2.4, Acpi 1.0b
• -soporta Dualbios-
• -use Of Licensed Award Bios

Otras Características

• -@bios-
• -auto Green
• -download Center
• -extreme Hard Drive
• -q-flash-
• -support For Cloud Oc
• -support For Dynamic Energy Saver- 2
• -support For Easytune
• * Available Functions In Easytune May Differ By Motherboard Model.
• -support For On / Off Charge
• -support For Q-share
• -support For Smart 6-
• -xpress- Install
• -soporta Xpress Bios Rescue
• -xpress- Recovery 2

Software Incluido

• -norton Internet Security (versión Oem)

Sistema Operativo

• -microsoft® Windows® 7 / Vista / Xp

Formato

• -atx, 305mm X 215mm

Garantía

• 2 Años
